Ethernet on Bare-Metal STM32MP135

Published 21 Jan 2026. Written by Jakob Kastelic.

In this writeup we’ll go through the steps needed to bring up the Ethernet peripheral (ETH1) on the STM32MP135 eval board as well as a custom board.

Eval board connections to PHY

The evaluation board uses the LAN8742A-CZ-TR Ethernet PHY chip, connected to the SoC as follows:

PHY pin	PHY signal	SoC signal	SoC pin	Alt. Fn.	Notes
16	`TXEN`	`PB11/ETH1_TX_EN`	`AA2`	AF11
17	`TXD0`	`PG13/ETH1_TXD0`	`AA9`	AF11
18	`TXD1`	`PG14/ETH1_TXD1`	`Y10`	AF11
8	`RXD0/MODE0`	`PC4/ETH1_RXD0`	`Y7`	AF11	10k PU
7	`RXD1/MODE1`	`PC5/ETH1_RXD1`	`AA7`	AF11	10k PU
11	`CRS_DV/MODE2`	`PC1/ETH1_CRS_DV`	`Y9`	AF10	10k PU
13	`MDC`	`PG2/ETH1_MDC`	`V3`	AF11
12	`MDIO`	`PA2/ETH1_MDIO`	`Y4`	AF11	1k5 PU
15	`nRST`	`ETH1_NRST`	`IO9`		MPC IO
14	`nINT/RECLKO`	`PA1/ETH1_RX_CLK`	`AA3`	AF11

Reset pin

In this design, the Ethernet PHY connected to ETH1 has its own 25MHz crystal. Note the ETH1_RX_CLK connection, which uses the MCP23017T-E/ML I2C I/O expander.

One wonders if it was really necessary to complicate Ethernet bringup by requiring this extra step (I2C + IO config) on an SoC that has 320 pins. True to form, the simple IO expander needs more than 1,300 lines of ST driver code plus lots more in the pointless BSP abstraction layer wrapper.

With a driver that complicated, it’s easier to start from scratch. As it happens, writing these GPIO pins involves just two I2C transactions. The I2C code is trivial, find it here.

Sending an Ethernet frame from eval board

Again ST code examples are very complex, but it takes just over 300 lines of code to send an Ethernet frame, by way of verifying that data can be transmitted over this interface. I asked ChatGPT to summarize what happens in the code:

Configure the pins for Ethernet First, all the GPIO pins required by the RMII interface are set up. Each pin is switched to its Ethernet alternate function, configured for push-pull output, and set to a high speed. This ensures the STM32’s MAC can physically drive the Ethernet lines correctly. If you’re using an external GPIO expander like the MCP23x17, it is also initialized here, and relevant pins are set high to enable the PHY or other control signals.
Enable the Ethernet clocks Before the MAC can operate, the clocks for the Ethernet peripheral—MAC, TX, RX, and the reference clock—are enabled in the RCC. This powers the Ethernet block inside the STM32 and allows it to communicate with the PHY.
Initialize descriptors and buffers DMA descriptors for transmit (TX) and receive (RX) are allocated and zeroed. The transmit buffer is allocated and aligned to 32 bytes, as required by the DMA. A TX buffer descriptor is created, pointing to the transmit buffer. This descriptor tells the HAL exactly where the frame data is and how long it is.
Configure the Ethernet peripheral structure The ETH_HandleTypeDef is populated with the MAC address, RMII mode, pointers to the TX and RX descriptors, and the RX buffer size. The clock source for the peripheral is selected. At this stage, the HAL has all the information needed to manage the hardware.
Initialize the MAC and PHY Calling HAL_ETH_Init() programs the MAC with the descriptor addresses, frame length settings, and other features like checksum offload. The PHY is reset and auto-negotiation is enabled via MDIO. Reading the PHY ID verifies that the PHY is responding correctly.
Start the MAC With HAL_ETH_Start(), the MAC begins normal operation, monitoring the RMII interface for frames to transmit or receive.
Build the Ethernet frame A frame is constructed in memory. The first 6 bytes are the destination MAC (broadcast in this case), the next 6 bytes are the source MAC (the STM32’s MAC), followed by a 2-byte EtherType. The payload is copied into the frame (e.g., a short test string), and the frame is padded to at least 60 bytes to satisfy Ethernet minimum length requirements.
Transmit the frame The TX buffer descriptor is updated with the frame length and pointer to the buffer. HAL_ETH_Transmit() is called, which programs the DMA to fetch the frame from memory and put it onto the Ethernet wire. After this call completes successfully, the frame is sent, and you can see it in Wireshark on the network.

For the record, when a cable is connected, the PHY sees the link is up:

> eth_status
Ethernet link is up
  Speed: 100 Mbps
  Duplex: full
  BSR = 0x782D, PHYSCSR = 0x1058

Custom board connections to PHY

The custom board (Rev A) also uses the LAN8742A-CZ-TR Ethernet PHY chip, connected to the SoC as follows:

PHY pin	PHY signal	SoC signal	SoC pin	Alt. Fn.	Notes
16	`TXEN`	`PB11/ETH1_TX_EN`	`N5`	AF11
17	`TXD0`	`PG13/ETH1_TXD0`	`P8`	AF11
18	`TXD1`	`PG14/ETH1_TXD1`	`P9`	AF11
8	`RXD0/MODE0`	`PC4/ETH1_RXD0`	`U6`	AF11	10k PU
7	`RXD1/MODE1`	`PC5/ETH1_RXD1`	`R7`	AF11	10k PU
11	`CRS_DV/MODE2`	`PA7/ETH1_CRS_DV`	`U2`	AF11	10k PU
13	`MDC`	`PG2/ETH1_MDC`	`R1`	AF11
12	`MDIO`	`PG3/ETH1_MDIO`	`L5`	AF11	1k5 PU
15	`nRST`	`PG11`	`M3`		10k PD
14	`nINT/RECLKO`	`PG12/ETH1_PHY_INTN`	`T1`	AF11	10k PU
5	`XTAL1/CLKIN`	`PA11/ETH1_CLK`	`T2`	AF11

The differences with respect to eval board are:

Signal	Eval board	Custom board
`ETH1_CRS_DV`	`PC1/ETH1_CRS_DV`	`PA7/ETH1_CRS_DV`
`ETH1_MDIO`	`PA2/ETH1_MDIO`	`PG3/ETH1_MDIO`
`nRST`	GPIO expander	`PG11`, 10k pulldown
`nINT/REFCLKO`	`PA1/ETH1_RX_CLK`	`PG12/ETH1_PHY_INTN`
`XTAL1/CLKIN`	25 MHz XTAL	`PA11/ETH1_CLK`

That is, two different port assignments, direct GPIO for reset instead of expander, clock to be output from the SoC to the PHY, and using INTN signal instead of RX_CLK. All alternate functions are 11, while on the eval board one of them (CRS_DV) was 10.

Transmit Ethernet frame from custom board

First, we need to set the clock correctly. Since Ethernet does not have a dedicated crystal on the custom board, we need to source it from a PLL. In particular, we can set PLL3Q to output 24/2*50/24=25 MHz, and select the ETH1 clock source:

pclk.PeriphClockSelection = RCC_PERIPHCLK_ETH1;
pclk.Eth1ClockSelection   = RCC_ETH1CLKSOURCE_PLL3;
if (HAL_RCCEx_PeriphCLKConfig(&pclk) != HAL_OK)
   ERROR("ETH1");

With the scope, I can see a 25 MHz clock on the ETH_CLK trace and the nRST pin is driven high (3.3V). Nonetheless, HAL_ETH_Init() returns with an error.

Of course, we forgot to tell the HAL what the Ethernet clock source is. On the eval board, we had

eth_handle.Init.ClockSelection = HAL_ETH1_REF_CLK_RX_CLK_PIN;

But on the custom board, the SoC provides the clock to the PHY:

eth_handle.Init.ClockSelection = HAL_ETH1_REF_CLK_RCC;

Mistake in HAL driver?

With the RCC clock selected for Ethernet, yet again HAL_ETH_Init() fails. This time, it tries to select the RCC clock source:

if (heth->Init.ClockSelection == HAL_ETH1_REF_CLK_RCC)
{
  syscfg_config |= SYSCFG_PMCSETR_ETH1_REF_CLK_SEL;
}
HAL_SYSCFG_ETHInterfaceSelect(syscfg_config);

The Ethernet interface and clocking setup is done in the PMCSETR register, together with some other configuration.

void HAL_SYSCFG_ETHInterfaceSelect(uint32_t SYSCFG_ETHInterface)
{
   assert_param(IS_SYSCFG_ETHERNET_CONFIG(SYSCFG_ETHInterface));
   SYSCFG->PMCSETR = (uint32_t)(SYSCFG_ETHInterface);
}

Now the driver trips over the assertion. The assertion macro expects the config word to pure interface selection, forgetting that the same register also carries the ETH1_REF_CLK_SEL field (amongst others!):

#define IS_SYSCFG_ETHERNET_CONFIG(CONFIG)                                      \
   (((CONFIG) == SYSCFG_ETH1_MII) || ((CONFIG) == SYSCFG_ETH1_RMII) ||         \
    ((CONFIG) == SYSCFG_ETH1_RGMII) || ((CONFIG) == SYSCFG_ETH2_MII) ||        \
    ((CONFIG) == SYSCFG_ETH2_RMII) || ((CONFIG) == SYSCFG_ETH2_RGMII))
#endif /* SYSCFG_DUAL_ETH_SUPPORT */

If we comment out this assertion, the initialization proceeds without further errors. However, link is still down.

Biasing transformer center taps

Even with an Ethernet cable plugged in, link is down:

// Read basic status register
if (HAL_ETH_ReadPHYRegister(&eth_handle, LAN8742_ADDR,
      LAN8742_BSR, &v) != HAL_OK) {
   my_printf("PHY BSR read failed\r\n");
   return;
}

if ((v & LAN8742_BSR_LINK_STATUS) == 0u) {
   my_printf("Link is down (no cable or remote inactive)\r\n");
   return;
}

On the schematic diagram of the custom board, we notice that the RJ-45 transformer center taps (TXCT, RXCT on the J1011F21PNL connector) are decoupled to ground, but are not connected to 3.3V unlike on the eval board. The LAN8742A datasheet does not talk about it explicitly, but instead shows a schematic diagram (Figure 3-23) where the two center taps are tied together and pulled up to 3.3V via a ferrite bead.

Tying the center taps to 3.3V, we still get no link. Printing the PHY Basic Status Register, we see:

Link is down (no cable or remote inactive)
BSR = 0x7809

This means: link down, auto-negotiation not complete.

REF_CLK pin is not outputting a 50 MHz clock but instead sits at about 3.3V.

LEDs and straps

The PHY chip shares LED pins with straps.

LED1 is shared with REGOFF and is tied to the anode of the LED, which pulls down the pin such that REGOFF=0 and the regulator is enabled. We measure that VDDCR is at 1.25V, which indicates that the internal regulator started successfully. During board operation, this pin is low (close to 0V).

LED2 is shared with the nINTSEL pin, and is connected to the LED cathode. During board operation, this pin is high (close to 3.3V). Selecting nINTSEL=1 means REF_CLK In Mode, as is explained in Table 3-6: “nINT/REFCLKO is an active low interrupt output. The REF_CLK is sourced externally and must be driven on the XTAL1/CLKIN pin.”

Section 3.7.4 explains further regarding the “Clock In” mode:

In REF_CLK In Mode, the 50 MHz REF_CLK is driven on the XTAL1/CLKIN pin. This is the traditional system configuration when using RMII […]

In REF_CLK In Mode, the 50 MHz REF_CLK is driven on the XTAL1/CLKIN pin. A 50 MHz source for REF_CLK must be available external to the device when using this mode. The clock is driven to both the MAC and PHY as shown in Figure 3-7.

Furthermore, according to Section 3.8.1.6 of the PHY datasheet, the absence of a pulldown resistor on LED2/nINTSEL pin means that LED2 output is active low. That means that the anode of LED2 should have been tied to VDD2A according to Fig. 3-15, rather than ground as is currently the case.

This means we have two alternatives:

Add a 10k pulldown from LED2/nINTSEL to ground, and flip the polarity of the LED (connect the PHY to anode, or pin 9 of the connector). This would select nINTSEL=0. In that case, a 25 MHz clock is to be provided to XTAL1/CLKIN.
Keep LED2/nINTSEL connected to the LED cathode, without any pulldown resistor. This selects nINTSEL=1. However, make sure to connect the LED anode (pin 9, +LEDR, of connector) to VDD2A instead of GND. In this case, a 50 MHz clock is to be provided to XTAL1/CLKIN.

In this instance I chose the latter option and ordered PLL3Q to output 24/2*50/12=50 MHz. The link is briefly up and the green LED2 blinks:

> eth_status
Ethernet link is up
  Speed: 100 Mbps
  Duplex: full
  BSR = 0x782D, PHYSCSR = 0x1058

But strange enough, when I check the status just a moment later, the link is down again:

> eth_status
Link is down (no cable or remote inactive)
BSR = 0x7809

Checking repeatedly, sometimes it’s up, and sometimes it’s down.

I see that the current drawn from the 3.3V supply switches between 0.08A and 0.13A continuously, every second or two.

Digging in registers

Printing out some more info in both situations:

Link is down (no cable or remote inactive)
  BSR = 0x7809, PHYSCSR = 0x0040, ISFR = 0x0098, SMR = 0x60E0, SCSIR = 0x0040
SYSCFG_PMCSETR = 0x820000
> e
Ethernet link is up
  Speed: 100 Mbps
  Duplex: full
  BSR = 0x782D, PHYSCSR = 0x1058, ISFR = 0x00CA, SMR = 0x60E0, SCSIR = 0x1058
SYSCFG_PMCSETR = 0x820000

PHY Basic Status Register BSR, when link is down, shows the following status:

No T4 ability
TX with full duplex ability
TX with half duplex ability
10 Mbps with full duplex ability
10 Mbps with half duplex ability
Auto-negotiate process not completed
No remote fault
Able to perform auto-negotiation function
Link is down
No jabber condition detected.
Supports extended capabilities registers

When link is up, BSR shows (of course) that link is up, and also that the auto-negotiate process completed.

The PHY Special Control/Status Register (PHYSCSR), when link is down, does not have a meaningful speed indication (000), or anything else. When link is up, it shows speed as 100BASE-TX full-duplex (110), and that auto-negotiation is done.

The PHY Interrupt Source Flag Register (PHYISFR), when link is down, shows Auto-Negotiation LP Acknowledge, Link Down (link status negated), and ENERGYON generated. When link is up, we get Auto-Negotiation Page Received, Auto-Negotiation LP Acknowledge, ENERGYON generated, and Wake on LAN (WoL) event detected.

The PHY Special Modes Register (PHYSMR), when link is either up or down, shows the same value: 0x60E0. This means that PHYAD=00000 (PHY address), and MODE=111 (transceiver mode of operation is set to “All capable. Auto-negotiation enabled.”.

The PHY Special Control/Status Indications Register (PHYSCSIR), when link is up, shows Reversed polarity of 10BASE-T, even though link is 100 Mbps.

SoC PMCSETR has two fields set: ETH1_SEL is set to 100, meaning RMII, and ETH1_REF_CLK_SEL is set to 1, meaning that the reference clock (RMII mode) comes from the RCC.

Solution: PLL config (again!)

Painfully obvious in retrospect, but the problem was that PLL3, from which we’ve derived the Ethernet clock, was set to fractional mode:

rcc_oscinitstructure.PLL3.PLLFRACV  = 0x1a04;
rcc_oscinitstructure.PLL3.PLLMODE   = RCC_PLL_FRACTIONAL;

If instead we derive the clock from PLL4, which is already set to integer mode, then sending the Ethernet frame just works, and the link gets up and stays up:

rcc_oscinitstructure.PLL4.PLLFRACV  = 0;
rcc_oscinitstructure.PLL4.PLLMODE   = RCC_PLL_INTEGER;
// ...
pclk.PeriphClockSelection = RCC_PERIPHCLK_ETH1;
pclk.Eth1ClockSelection   = RCC_ETH1CLKSOURCE_PLL4;

Of course! Ethernet requires a perfectly precise 50 MHz clock, up to about 50 ppm. On the eval board that was not a problem: the PHY had its own crystal, and it returned a good 50 MHz clock directly back to the SoC’s MAC.
