This is Part 5 in the series: Linux on STM32MP135. See other articles.
Arm chips, such as the STM32MP135, implementing the TrustZone extension divide the execution into two worlds: a normal, non-secure world inhabited by the application operating system, and a secure world serviced by a secure OS such as OP-TEE. The ST wiki[1] assures us that OP-TEE is required on all STM32MP1 produces “due to the hardware architecture”. It is our purpose in this article to show that that is not the case: OP-TEE is in fact entirely optional.
The only mechanism to enter the “secure world” is via the SMC instruction
(secure monitor call). This is analogous to how user-space applications invoke
kernel system calls via the SVC (supervisor call) instruction to enter
privileged mode. So long as the kernel does not issue the SMC instruction, the
secure world need never be entered. Thus, we can restate our purpose as removing
all secure monitor calls from the kernel configuration.
The tutorial in the present article is somewhat more involved than the preceding ones in the series. For this reason I offer the “Quick Start” version, where the required modifications to kernel drivers are offered as patches to apply to a particular version. For those interested, the “Theory” and “Long Version” sections fill in the details. As in other articles, we conclude with a brief discussion.
TBD: copy from the stm32mp135_simple README.
To understand the modifications we are about to do in the next section, we need
to take a closer look at the boot process from TF-A to OP-TEE to Linux. In
particular, we need to explain how secure monitor calls (SMC) calls work; the
use of secure interrupts (FIQ) in OP-TEE; and explain how SCMI clocks work
When Arm Trusted Firmware (TF-A) is done with its own initialization, it loads
several images into memory. In the STM32MP1 case, these are defined in the
array bl2_mem_params_desc in file
plat/st/stm32mp1/plat_bl2_mem_params_desc.c, and include the following:
FW_CONFIG_ID: firmware config, which is mostly just the information on
TrustZone memory regions that is used by TF-A itself
BL32_IMAGE_ID: the OP-TEE executable
BL32_EXTRA1_IMAGE_ID, BL32_EXTRA2_IMAGE_ID, and TOS_FW_CONFIG_ID: some
stuff needed by OP-TEE
BL33_IMAGE_ID: the non-trusted bootloader (U-Boot) or directly Linux itself,
if operating in the “falcon mode”
HW_CONFIG_ID: the Device Tree Blob (DTB) used by U-Boot or Linux, whichever
is run as “BL33”
Just before passing control to OP-TEE, the TF-A prints a couple messages in the
bl2_main() function (bl2/bl2_main.c), and then runs bl2_run_next_image
(bl2/aarch32/bl2_run_next_image.S). There, we disable MMU, put the OP-TEE
entry address into the link register (either lr or lr_svc), load the SPSR
register, and then do an “exception return” to atomically change the program
counter to the link register value, and restore the Current Program Status
Register (CPSR) from the Saved Program Status Register (SPSR).
The ARMv7-A architecture provides optional TrustZone extension, which are implemented on the STM32MP135 chips (as well as the virtualisation extension). In this scheme, the processor is at all times executing in one of two “worlds”, either the secure or the non-secure one.
The NS bit of the
SCR
register defines which world we’re currently in. If NS=1, we are in non-secure
world, otherwise we’re in the secure world. The one exception to this is that
when the processor is running in
Monitor mode;
in that case, the code is executing the secure world and SCR.NS merely
indicates which world the processor was in before entering the Monitor mode.
(The current processor mode is given by the M bits of the
CPSR
register.)
The processor starts execution in the secure world. How do we transition to the
non-secure world? Outside of Monitor mode, Arm does not recommend direct
manipulation of the SCR.NS bit to change from the secure world to the
non-secure world or vice versa. Instead, the right way is to first change into
Monitor mode, flip the SCR.NS bit, and leave monitor mode. To enter Monitor
mode, execute the SMC instruction. This triggers the SMC exception, and the
processor begins executing the SMC handler.
The location of the SMC handler has to be previously stored in the
MVBAR register.
The initial setup required is as follows:
Write a SMC handler. As an example, consult OP-TEE source code, which
provides the handler sm_smc_entry, defined in core/arch/arm/sm/sm_a32.S.
Create a vector table for monitor mode. As specified in the Arm architecture manual, the monitor vector table has eight entries:
IRQ interrupt handlerFIQ interrupt handlerObviously entry number 3 has to point to the SMC handler defined previously.
For example, OP-TEE defines the following vector table in
core/arch/arm/sm/sm_a32.S:
LOCAL_FUNC sm_vect_table , :, align=32
UNWIND( .cantunwind)
b . /* Reset */
b . /* Undefined instruction */
b sm_smc_entry /* Secure monitor call */
b . /* Prefetch abort */
b . /* Data abort */
b . /* Reserved */
b . /* IRQ */
b sm_fiq_entry /* FIQ */
END_FUNC sm_vect_table
We see only the SMC and FIQ handlers are installed, since OP-TEE setup
disables all other Monitor-mode interrupts and exceptions.
Install the vector table to the MVBAR register. The OP-TEE source code
defines the following macros in out/core/include/generated/arm32_sysreg.h:
/* Monitor Vector Base Address Register */
static inline __noprof uint32_t read_mvbar(void)
{
uint32_t v;
asm volatile ("mrc p15, 0, %0, c12, c0, 1" : "=r" (v));
return v;
}
/* Monitor Vector Base Address Register */
static inline __noprof void write_mvbar(uint32_t v)
{
asm volatile ("mcr p15, 0, %0, c12, c0, 1" : : "r" (v));
}
This merely follows the Arm manual on how to access the
MVBAR register.
With this setup in place, to transition from the secure world to the non-secure world, the steps are as follows:
Place the arguments to the SMC handler into registers r0 through r4 (or
as many as are needed by the handler), and execute the SMC instruction. For
example, just before passing control to the non-secure world, OP-TEE
reset_primary function (called from the _start function) does the
following:
mov r4, #0
mov r3, r6
mov r2, r7
mov r1, #0
mov r0, #TEESMC_OPTEED_RETURN_ENTRY_DONE
smc #0
This puts the processor into Monitor mode, and it begins execution at the
previously-installed SMC handler. The handler stores secure-mode registers
into some memory location for future use, then sets the SCR.NS bit:
read_scr r0
orr r0, r0, #(SCR_NS | SCR_FIQ) /* Set NS and FIQ bit in SCR */
write_scr r0
This also sets the SCR.FIQ bit, which means that FIQ interrupts are also
taken to Monitor mode. In this way, OP-TEE assigns IRQ interrupts to the
non-secure world, and FIQ interrupts to the secure-world. Of course, this
means that the Monitor-mode vector table needs a FIQ handler (as mentioned
in passing above), and the system interrupt handler (GIC on STM32MP135) needs
to be configured to pass “secure” interrupts as FIQ.
After adjusting the stack pointer and restoring the non-secure register values from the stack, the SMC handler returns:
add sp, sp, #(SM_CTX_NSEC + SM_NSEC_CTX_R0)
pop {r0-r7}
rfefd sp!
The return location and processor mode is stored on the stack and
automatically retrieved by the rfefd sp! instruction. Of course this means
they have to be previously stored in the right place on the stack; see
sm_smc_entry source code for details.
As mentioned above, OP-TEE code, before returning to non-secure mode, enables
the SCR.FIQ bit, which means that FIQ interrupts get taken to Monitor mode,
serviced by the FIQ handler that is installed in the Monitor-mode vector table
(the table address is stored in the MVBAR register).
As mentioned above, an arbitrary number of system interrupts may be passed as a
FIQ to the processor core. OP-TEE handles these interrupts in itr_handle()
(defined in core/kernel/interrupt.c). The individual interrupt handlers are
stored in a linked list, which itr_handle() traverses until it finds a handler
whose interrupt number (h->it) matches the given interrupt.
For example, the handler for the TZC interrupt (TrustZone memory protection)
is defined in core/arch/arm/plat-stm32mp1/plat_tzc400.c, as the
tzc_it_handler() function.
In general, to configure clocks, Linux uses the
Common Clock Framework. Each
clock needs to define some common operations, such as enable(), disable(),
set_rate(), and so on, as relevant to each particular clock.
Since in the ST-recommended scheme the clock configuration is done entirely in
the secure world, the STM32MP135 clock drivers
(drivers/clk/stm32/clk-strm32mp13.c) make use of the SCMI clock driver
(drivers/clk/clk/scmi.c). The latter provides a translation from the common
clock functions to SCMI functions. For example, enable() is implemented as
follows:
static int scmi_clk_enable(struct clk_hw *hw)
{
struct scmi_clk *clk = to_scmi_clk(hw);
return scmi_proto_clk_ops->enable(clk->ph, clk->id);
}
This is just a wrapper around the SCMI clock enable function, as found in the
scmi_proto_clk_ops structure (which contains all the SCMI-protocol clock
operations).
At Linux boot, when the SCMI clock driver is being “probed”, it asks OP-TEE
about the number of supported clocks, and then retrieves information about each
one in sequence. Thus it acquires a list of clocks, with a header file defining
the sequential ID numbers (include/dt-bindings/clock/stm32mp13-clks.h):
/* SCMI clock identifiers */
#define CK_SCMI_HSE 0
#define CK_SCMI_HSI 1
#define CK_SCMI_CSI 2
#define CK_SCMI_LSE 3
#define CK_SCMI_LSI 4
#define CK_SCMI_HSE_DIV2 5
#define CK_SCMI_PLL2_Q 6
#define CK_SCMI_PLL2_R 7
#define CK_SCMI_PLL3_P 8
#define CK_SCMI_PLL3_Q 9
#define CK_SCMI_PLL3_R 10
#define CK_SCMI_PLL4_P 11
#define CK_SCMI_PLL4_Q 12
#define CK_SCMI_PLL4_R 13
#define CK_SCMI_MPU 14
#define CK_SCMI_AXI 15
#define CK_SCMI_MLAHB 16
#define CK_SCMI_CKPER 17
#define CK_SCMI_PCLK1 18
#define CK_SCMI_PCLK2 19
#define CK_SCMI_PCLK3 20
#define CK_SCMI_PCLK4 21
#define CK_SCMI_PCLK5 22
#define CK_SCMI_PCLK6 23
#define CK_SCMI_CKTIMG1 24
#define CK_SCMI_CKTIMG2 25
#define CK_SCMI_CKTIMG3 26
#define CK_SCMI_RTC 27
#define CK_SCMI_RTCAPB 28
(There must be some way to ensure that the same sequential number is used in Linux as in OP-TEE, or else the clocks would get confused. Presumably the same header file is used in Linux as in OP-TEE.)
The SCMI clock numbers are then used in device trees. For example, in
core/arch/arm/dts/stm32mp131.dtsi, we see some of these constants being used:
rcc: rcc@50000000 {
compatible = "st,stm32mp13-rcc", "syscon";
reg = <0x50000000 0x1000>;
#clock-cells = <1>;
#reset-cells = <1>;
clock-names = "hse", "hsi", "csi", "lse", "lsi";
clocks = <&scmi_clk CK_SCMI_HSE>,
<&scmi_clk CK_SCMI_HSI>,
<&scmi_clk CK_SCMI_CSI>,
<&scmi_clk CK_SCMI_LSE>,
<&scmi_clk CK_SCMI_LSI>;
};
Thus, when the driver compatible with "st,stm32mp13-rcc" (implemented in
drivers/clk/stm32/clk-stm32mp13.c) needs to refer to its "hse" clock, it
calls the scmi_clk and gives it the CK_SCMI_HSE parameter. Recall that
scmi_clk is defined in the same DTSI file, under firmware / scmi:
scmi_clk: protocol@14 {
reg = <0x14>;
#clock-cells = <1>;
};
There are some SCMI clocks, however, which are used by the "st,stm32mp13-rcc"
driver, which are not listed in the device tree. For example, in
drivers/clk/stm32/clk-stm32mp13.c we find many definitions such as the
following:
static const char * const sdmmc12_src[] = {
"ck_axi", "pll3_r", "pll4_p", "ck_hsi"
};
Here ck_axi, pll3_r, etc., refer to SCMI clocks, but these are not mentioned
in the device tree. How can the kernel find them? The way it works is that
during SCMI clock driver initialization, the driver registers these clocks (and
others as per the listing from the stm32mp13-clks.h header file above). When,
later, the "st,stm32mp13-rcc" driver is being initialized, it is able to refer
to these clocks simply by their name.
This means that the SCMI driver needs to be probed before the RCC driver. To
ensure this, note the following part of the device tree:
rcc: rcc@50000000 {
...
clocks = <&scmi_clk CK_SCMI_HSE>,
<&scmi_clk CK_SCMI_HSI>,
<&scmi_clk CK_SCMI_CSI>,
<&scmi_clk CK_SCMI_LSE>,
<&scmi_clk CK_SCMI_LSI>;
};
The reference to SCMI clocks here does not mean that these particular clocks
(HSE, HSI, CSI, LSE, LSI) are used by the RCC driver. Rather, it
ensures that the SCMI clock driver is a dependency of the RCC driver, and gets
initialized first. It would have been much nicer if the device tree RCC node
listed all the clocks that are used by RCC rather than just referring to them
by their name string (such as "pll3_r"), but that’s the way ST implemented
things. In particular, this means that if we unset the CONFIG_COMMON_CLK_SCMI
entry in the kernel configuration, the kernel will no longer boot, without
printing any error message at all; the RCC driver will fail to work properly
since it can no longer refer to many of the clocks it needs by their name
string.
There is no need to understand SCMI clocks further, so long as we can replace
them all with “real” clocks, with registers under direct control of the RCC
driver from the Linux kernel.
We now proceed with the “long version” of the tutorial make Linux boot on the STM32MP135 eval board without running OP-TEE in the background.
We begin with the defconfig modified to not require U-Boot, such as the one created in the previous article (probably optional, but I mention it so we can all start from the same starting point).
Having that set up and working, we will need to do the following tasks, as explained in the coming subsections:
STPMIC1 and I2C4 from OP-TEE to the Linux kernelRCC) from Arm Trusted Firmware (TF-A)RCC registersSTPMIC1 and I2C4 from OP-TEE to LinuxMove the entire &i2c4 {...} tree (about 180 lines of code!) from the OP-TEE
device tree source (optee-os-4.3.0/core/arch/arm/dts/stm32mp135f-dk.dts) to
the Linux DTS (linux-6.12.36/arch/arm/boot/dts/st/stm32mp135f-dk.dts).
OP-TEE will not need to know about I2C4 and STPMIC1, but Linux will.
Also copy over the vin: vin { ... } and v3v3_ao: v3v3_ao { ... } nodes.
Notice that the &i2c4 tree refers to pinctrl-0 = <&i2c4_pins_a>, which is
not defined by default. Without it, the driver will not know what pins we’re
using for the I2C4 peripheral. Copy the pin mux definition to the
appropriate Linux DTS file (arch/arm/boot/dts/stm32mp13-pinctrl.dtsi) from
the corresponding OP-TEE file (core/arch/arm/dts/stm32mp13-pinctrl.dtsi):
i2c4_pins_a: i2c4-0 {
pins {
pinmux = <STM32_PINMUX('E', 15, AF6)>, /* I2C4_SCL */
<STM32_PINMUX('B', 9, AF6)>; /* I2C4_SDA */
bias-disable;
drive-open-drain;
slew-rate = <0>;
};
};
The Linux driver for the STPMIC1 requires two small changes. In
drivers/regulator/stpmic1_regulator.c, we need to tell it that the switched
regulator (pwr_sw2 in the device tree, and 3V3_SW on the STM32MP135F-DK
schematic) is 3.3V, not 5V. Locate the lines starting with #define REG_SW_OUT(ids, base) { \ and change the following .fixed_uV = 5000000 to
.fixed_uV = 3300000.
The second change is in file drivers/mfd/stpmic1.c. In function
stpmic1_probe(), comment out (or remove) the lines
if (ddata->irq < 0) {
dev_err(dev, "Failed to get main IRQ: %d\n", ddata->irq);
return ddata->irq;
}
and also
/* Initialize PMIC IRQ Chip & associated IRQ domains */
ret = devm_regmap_add_irq_chip(dev, ddata->regmap, ddata->irq,
IRQF_ONESHOT | IRQF_SHARED,
0, &stpmic1_regmap_irq_chip,
&ddata->irq_data);
if (ret) {
dev_err(dev, "IRQ Chip registration failed: %d\n", ret);
return ret;
}
Remove all references to SCMI from the Linux DTS
(linux-6.12.36/arch/arm/boot/dts/st/stm32mp135f-dk.dts), making sure they
are replaced with corresponding references to the STPMIC1:
scmi_v3v3_sw -> v3v3_swscmi_vdd_adc -> vdd_adcscmi_vdd_sd -> vdd_sdscmi_vdd_usb -> vdd_usbscmi_v1v8_periph -> v1v8_periph&scmi_regu { ... } treeNote with all these changes, OP-TEE may no longer work (without further changes
or additions). This is not a problem, since the whole point here is to remove
I2C4 from OP-TEE’s control.
Make a copy of the TF-A DTS file, so that it will persist from build to
build. Note the location and set it in the Buildroot configuration. For
example, set
$(BR2_EXTERNAL_THINKSRS_PATH)/board/stm32mp1/TFA_stm32mp135f-dk.dts in the
configuration option BR2_TARGET_ARM_TRUSTED_FIRMWARE_CUSTOM_DTS_PATH.
Likewise, make a copy of the file stm32mp135f-dk-fw-config.dts, and include
it in the same configuration option.
Copy the entire &rcc { ... } section from the OP-TEE DTS to the TF-A DTS,
except for the two pinctrl lines at the top. In this case, it looks like
this:
&rcc {
compatible = "st,stm32mp13-rcc", "syscon", "st,stm32mp13-rcc-mco";
st,clksrc = <
CLK_MPU_PLL1P
CLK_AXI_PLL2P
CLK_MLAHBS_PLL3
CLK_RTC_LSE
CLK_MCO1_HSE
CLK_MCO2_DISABLED
CLK_CKPER_HSE
CLK_ETH1_PLL4P
CLK_ETH2_PLL4P
CLK_SDMMC1_PLL4P
CLK_SDMMC2_PLL4P
CLK_STGEN_HSE
CLK_USBPHY_HSE
CLK_I2C4_HSI
CLK_I2C5_HSI
CLK_USBO_USBPHY
CLK_ADC2_CKPER
CLK_I2C12_HSI
CLK_UART1_HSI
CLK_UART2_HSI
CLK_UART35_HSI
CLK_UART4_HSI
CLK_UART6_HSI
CLK_UART78_HSI
CLK_SAES_AXI
CLK_DCMIPP_PLL2Q
CLK_LPTIM3_PCLK3
CLK_RNG1_PLL4R
>;
st,clkdiv = <
DIV(DIV_MPU, 1)
DIV(DIV_AXI, 0)
DIV(DIV_MLAHB, 0)
DIV(DIV_APB1, 1)
DIV(DIV_APB2, 1)
DIV(DIV_APB3, 1)
DIV(DIV_APB4, 1)
DIV(DIV_APB5, 2)
DIV(DIV_APB6, 1)
DIV(DIV_RTC, 0)
DIV(DIV_MCO1, 0)
DIV(DIV_MCO2, 0)
>;
st,pll_vco {
pll1_vco_2000Mhz: pll1-vco-2000Mhz {
src = <CLK_PLL12_HSE>;
divmn = <1 82>;
frac = <0xAAA>;
};
pll1_vco_1300Mhz: pll1-vco-1300Mhz {
src = <CLK_PLL12_HSE>;
divmn = <2 80>;
frac = <0x800>;
};
pll2_vco_1066Mhz: pll2-vco-1066Mhz {
src = <CLK_PLL12_HSE>;
divmn = <2 65>;
frac = <0x1400>;
};
pll3_vco_417Mhz: pll3-vco-417Mhz {
src = <CLK_PLL3_HSE>;
divmn = <1 33>;
frac = <0x1a04>;
};
pll4_vco_600Mhz: pll4-vco-600Mhz {
src = <CLK_PLL4_HSE>;
divmn = <1 49>;
};
};
/* VCO = 1300.0 MHz => P = 650 (CPU) */
pll1: st,pll@0 {
compatible = "st,stm32mp1-pll";
reg = <0>;
st,pll = <&pll1_cfg1>;
pll1_cfg1: pll1_cfg1 {
st,pll_vco = <&pll1_vco_1300Mhz>;
st,pll_div_pqr = <0 1 1>;
};
pll1_cfg2: pll1_cfg2 {
st,pll_vco = <&pll1_vco_2000Mhz>;
st,pll_div_pqr = <0 1 1>;
};
};
/* VCO = 1066.0 MHz => P = 266 (AXI), Q = 266, R = 533 (DDR) */
pll2: st,pll@1 {
compatible = "st,stm32mp1-pll";
reg = <1>;
st,pll = <&pll2_cfg1>;
pll2_cfg1: pll2_cfg1 {
st,pll_vco = <&pll2_vco_1066Mhz>;
st,pll_div_pqr = <1 1 0>;
};
};
/* VCO = 417.8 MHz => P = 209, Q = 24, R = 11 */
pll3: st,pll@2 {
compatible = "st,stm32mp1-pll";
reg = <2>;
st,pll = <&pll3_cfg1>;
pll3_cfg1: pll3_cfg1 {
st,pll_vco = <&pll3_vco_417Mhz>;
st,pll_div_pqr = <1 16 36>;
};
};
/* VCO = 600.0 MHz => P = 50, Q = 10, R = 50 */
pll4: st,pll@3 {
compatible = "st,stm32mp1-pll";
reg = <3>;
st,pll = <&pll4_cfg1>;
pll4_cfg1: pll4_cfg1 {
st,pll_vco = <&pll4_vco_600Mhz>;
st,pll_div_pqr = <11 59 11>;
};
};
st,clk_opp {
/* CK_MPU clock config for MP13 */
st,ck_mpu {
cfg_1 {
hz = <650000000>;
st,clksrc = <CLK_MPU_PLL1P>;
st,pll = <&pll1_cfg1>;
};
cfg_2 {
hz = <1000000000>;
st,clksrc = <CLK_MPU_PLL1P>;
st,pll = <&pll1_cfg2>;
};
};
};
};
From the OP-TEE DTS $rcc { ... } section, remove everything except:
&rcc {
compatible = "st,stm32mp13-rcc", "syscon", "st,stm32mp13-rcc-mco";
st,clksrc = <
CLK_RNG1_PLL4R
>;
st,clkdiv = <
DIV(DIV_MPU, 1)
>;
};
This is needed because of a bug in the OP-TEE rcc driver, where it attempts
to set the dividers and clocks even if none are provided.
Now all the clocks are effectively set by TF-A.
To relieve OP-TEE of the ETZPC configuration duty, follow these steps:
To include the ETZPC driver in the Arm Trusted Firmware (TF-A) makefile, add
the following line at the end of plat/st/common/common.mk:
BL2_SOURCES += drivers/st/etzpc/etzpc.c
In the STM32MP1 platform files included in TF-A, the ETZPC DECPROT
assignments are incorrect. Replace all of STM32MP1_ETZPC_ defines in
plat/st/stm32mp1/stm32mp1_def.h with the values given in Table 85, “DECPROT
assignment”, of the STM32MP13xx Reference manual:
#define STM32MP1_ETZPC_VREFBUF_ID 0
#define STM32MP1_ETZPC_LPTIM2_ID 1
#define STM32MP1_ETZPC_LPTIM3_ID 2
#define STM32MP1_ETZPC_LTDC_ID 3
#define STM32MP1_ETZPC_DCMIPP_ID 4
#define STM32MP1_ETZPC_USBPHYCTRL_ID 5
#define STM32MP1_ETZPC_DDRCTRLPHY_ID 6
#define STM32MP1_ETZPC_IWDG1_ID 12
#define STM32MP1_ETZPC_STGENC_ID 13
#define STM32MP1_ETZPC_USART1_ID 16
#define STM32MP1_ETZPC_USART2_ID 17
#define STM32MP1_ETZPC_SPI4_ID 18
#define STM32MP1_ETZPC_SPI5_ID 19
#define STM32MP1_ETZPC_I2C3_ID 20
#define STM32MP1_ETZPC_I2C4_ID 21
#define STM32MP1_ETZPC_I2C5_ID 22
#define STM32MP1_ETZPC_TIM12_ID 23
#define STM32MP1_ETZPC_TIM13_ID 24
#define STM32MP1_ETZPC_TIM14_ID 25
#define STM32MP1_ETZPC_TIM15_ID 26
#define STM32MP1_ETZPC_TIM16_ID 27
#define STM32MP1_ETZPC_TIM17_ID 28
#define STM32MP1_ETZPC_ADC1_ID 32
#define STM32MP1_ETZPC_ADC2_ID 33
#define STM32MP1_ETZPC_OTG_ID 34
#define STM32MP1_ETZPC_RNG_ID 40
#define STM32MP1_ETZPC_HASH_ID 41
#define STM32MP1_ETZPC_CRYP_ID 42
#define STM32MP1_ETZPC_SAES_ID 43
#define STM32MP1_ETZPC_PKA_ID 44
#define STM32MP1_ETZPC_BKPSRAM_ID 45
#define STM32MP1_ETZPC_ETH1_ID 48
#define STM32MP1_ETZPC_ETH2_ID 49
#define STM32MP1_ETZPC_SDMMC1_ID 50
#define STM32MP1_ETZPC_SDMMC2_ID 51
#define STM32MP1_ETZPC_MCE_ID 53
#define STM32MP1_ETZPC_FMC_ID 54
#define STM32MP1_ETZPC_QSPI_ID 55
#define STM32MP1_ETZPC_SRAM1_ID 60
#define STM32MP1_ETZPC_SRAM2_ID 61
#define STM32MP1_ETZPC_SRAM3_ID 62
Add the ETZPC node to the TF-A DTS file (fdts/stm32mp131.dtsi), under soc { ... }:
etzpc: etzpc@5c007000 {
compatible = "st,stm32mp13-etzpc";
reg = <0x5c007000 0x400>;
clocks = <&rcc TZPC>;
#address-cells = <1>;
#size-cells = <1>;
};
In the platform-specific TF-A BL2 (that is, bootloader) file
plat/st/stm32mp1/bl2_plat_setup.c, add the ETZPC driver header file:
#include <drivers/st/etzpc.h>
Later in the same file, at the end of the function bl2_platform_setup(),
add the desired ETZPC configuration:
/* Configure ETZPC */
if (etzpc_init() != 0) {
panic();
}
etzpc_configure_decprot(STM32MP1_ETZPC_SDMMC1_ID, ETZPC_DECPROT_NS_RW);
Repeat this process with as many etzpc_configure_decprot() calls as
required for one’s needs. For example, to duplicate the OP-TEE configuration
(except for unsecuring I2C4, as per the steps at the beginning of this
guide), we need the following:
etzpc_configure_decprot(STM32MP1_ETZPC_ADC1_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_ADC2_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_BKPSRAM_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_CRYP_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_DCMIPP_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_DDRCTRLPHY_ID, ETZPC_DECPROT_NS_R_S_W);
etzpc_configure_decprot(STM32MP1_ETZPC_ETH1_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_ETH2_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_FMC_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_HASH_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_I2C3_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_I2C4_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_I2C5_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_IWDG1_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_LPTIM2_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_LPTIM3_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_LTDC_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_MCE_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_OTG_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_PKA_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_QSPI_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_RNG_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_SAES_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_SDMMC1_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_SDMMC2_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_SPI4_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_SPI5_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_SRAM1_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_SRAM2_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_SRAM3_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_STGENC_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_TIM12_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_TIM13_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_TIM14_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_TIM15_ID, ETZPC_DECPROT_S_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_TIM16_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_TIM17_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_USART1_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_USART2_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_USBPHYCTRL_ID, ETZPC_DECPROT_NS_RW);
etzpc_configure_decprot(STM32MP1_ETZPC_VREFBUF_ID, ETZPC_DECPROT_NS_RW);
Remove the ETZPC section (&etzpc {...}) from the OP-TEE DTS file
core/arch/arm/dts/stm32mp135f-dk.dts.
Instead of following steps 1 through 6, we can apply the patch file
0001-allow-large-bl33-and-config-etzpc-rcc.patch to the TF-A code.
At this stage, Linux is still issuing many SMC calls. We can see that by inserting a function that prints a message into the OP-TEE SMC handler, as follows.
In OP-TEE, define two “print” functions in core/arch/arm/kernel/boot.c:
void __print_from_secure_smc(void)
{
EMSG_RAW("SMC from Secure");
}
void __print_from_nonsecure_smc(void)
{
EMSG_RAW("SMC from Non-Secure");
}
Call these two functions from the OP-TEE secure monitor call (SMC) handler.
Open core/arch/arm/sm/sm_a32.S, in function sm_smc_entry, and call
__print_from_secure_smc() after checking the SCR_NS bit:
/* Find out if we're doing an secure or non-secure entry */
read_scr r1
tst r1, #SCR_NS
bne .smc_from_nsec
bl __print_from_secure_smc
A couple lines later, insert the “print from non-secure”:
.smc_from_nsec:
bl __print_from_nonsecure_smc
In the default configuration, I count as many as 1017 “SMC from Non-Secure”
messages reported by OP-TEE. What is going on? Some clues are to be found in the
Linux DTS file, arch/arm/boot/dts/stm32mp131.dtsi. In the firmware { ... }
section, there is an optee node with method = "smc", as well as a scmi
sub-tree, listing scmi_perf, scmi_clk, scmi_reset, and scmi_voltd. We
need to go through these one by one and see whether they can be removed.
RCC registersBefore Linux can do its own clock configuration, RCC must be set so as to
allow non-secure access to the clock configurations. According to the STM32MP135
reference manual, the RCC_SECCFGR register can be used to “securely allocate
and partition each corresponding RCC resource/sub-function either to the
secure world or to the non-secure world.”
In TF-A, add the following at the end of bl2_platform_setup() in file
plat/st/stm32mp1/bl2_plat_setup.c:
/* Allow non-secure access to all RCC clocks */
mmio_write_32(stm32mp_rcc_base() + RCC_SECCFGR, 0);
(Optional.) To confirm that the clocks stay unsecured through the boot
process (in particular, that OP-TEE does not mess with it), we can add the
following function to the Linux RCC driver in
drivers/clk/stm32/clk-stm-32-core.c:
#include "stm32mp13_rcc.h"
void print_seccfgr(void __iomem *rcc_base)
{
/* Read RCC secure configuration register */
uint32_t seccfgr = ioread32(rcc_base + RCC_SECCFGR);
printk(KERN_WARNING "Hello2! RCC_SECCFGR = 0x%x\n", seccfgr);
const char* names[] = {
"RCC_SECCFGR_HSISEC", "RCC_SECCFGR_CSISEC", "RCC_SECCFGR_HSESEC",
"RCC_SECCFGR_LSISEC", "RCC_SECCFGR_LSESEC", "Res", "Res", "Res",
"RCC_SECCFGR_PLL12SEC", "RCC_SECCFGR_PLL3SEC", "RCC_SECCFGR_PLL4SEC",
"RCC_SECCFGR_MPUSEC", "RCC_SECCFGR_AXISEC", "RCC_SECCFGR_MLAHBSEC",
"Res", "Res", "RCC_SECCFGR_APB3DIVSEC", "RCC_SECCFGR_APB4DIVSEC",
"RCC_SECCFGR_APB5DIVSEC", "RCC_SECCFGR_APB6DIVSEC",
"RCC_SECCFGR_TIMG3SEC", "RCC_SECCFGR_CPERSEC", "RCC_SECCFGR_MCO1SEC",
"RCC_SECCFGR_MCO2SEC", "RCC_SECCFGR_STPSEC", "RCC_SECCFGR_RSTSEC",
"Res", "Res", "Res", "Res", "Res", "RCC_SECCFGR_PWRSEC",
};
for (int i=0; i<32; i++) {
printk(KERN_WARNING "%s\t\t\t%s\r\n", names[i],
((seccfgr & (1U << i)) == 0) ? ("Non-Secure") : ("Secure"));
}
}
Call this function at the end of stm32_rcc_init():
int stm32_rcc_init(struct device *dev, const struct of_device_id *match_data,
void __iomem *base)
{
...
print_seccfgr(base);
return 0;
}
If everything works out, the following printout appears in the kernel log when it boots:
[ 4.756561] Hello2! RCC_SECCFGR = 0x0
[ 4.756637] RCC_SECCFGR_HSISEC Non-Secure
[ 4.756668] RCC_SECCFGR_CSISEC Non-Secure
[ 4.756693] RCC_SECCFGR_HSESEC Non-Secure
[ 4.756718] RCC_SECCFGR_LSISEC Non-Secure
[ 4.756742] RCC_SECCFGR_LSESEC Non-Secure
[ 4.756766] Res Non-Secure
[ 4.756788] Res Non-Secure
[ 4.756809] Res Non-Secure
[ 4.756831] RCC_SECCFGR_PLL12SEC Non-Secure
[ 4.756855] RCC_SECCFGR_PLL3SEC Non-Secure
[ 4.756880] RCC_SECCFGR_PLL4SEC Non-Secure
[ 4.756904] RCC_SECCFGR_MPUSEC Non-Secure
[ 4.756928] RCC_SECCFGR_AXISEC Non-Secure
[ 4.756951] RCC_SECCFGR_MLAHBSEC Non-Secure
[ 4.756975] Res Non-Secure
[ 4.756997] Res Non-Secure
[ 4.757019] RCC_SECCFGR_APB3DIVSEC Non-Secure
[ 4.757043] RCC_SECCFGR_APB4DIVSEC Non-Secure
[ 4.757068] RCC_SECCFGR_APB5DIVSEC Non-Secure
[ 4.757093] RCC_SECCFGR_APB6DIVSEC Non-Secure
[ 4.757117] RCC_SECCFGR_TIMG3SEC Non-Secure
[ 4.757142] RCC_SECCFGR_CPERSEC Non-Secure
[ 4.757242] RCC_SECCFGR_MCO1SEC Non-Secure
[ 4.757273] RCC_SECCFGR_MCO2SEC Non-Secure
[ 4.757298] RCC_SECCFGR_STPSEC Non-Secure
[ 4.757323] RCC_SECCFGR_RSTSEC Non-Secure
[ 4.757347] Res Non-Secure
[ 4.757369] Res Non-Secure
[ 4.757390] Res Non-Secure
[ 4.757412] Res Non-Secure
[ 4.757433] Res Non-Secure
[ 4.757455] RCC_SECCFGR_PWRSEC Non-Secure
See section 10.8.1, “RCC secure configuration register (RCC_SECCFGR)”, of
the STM32MP135 reference manual for more information about the above printout.
In this section, we explain how to configure all necessary system clocks directly from the Linux kernel, without the use of SMC calls to OP-TEE via the SCMI protocol.
Disable CONFIG_COMMON_CLK_SCMI entry in the kernel configuration (under
Device Drivers -> Common Clock Framework -> Clock driver controlled via SCMI
interface). This prevents the inclusion of the SCMI clock driver
(clk-scmi.c), and thereby the registration of unnecessary SCMI clocks.
Additionally, the following entries will not be needed:
CONFIG_ARM_SCMI_POWER_DOMAIN
CONFIG_SENSORS_ARM_SCMI
CONFIG_REGULATOR_ARM_SCMI
CONFIG_RESET_SCMI
CONFIG_ARM_SCMI_TRANSPORT_MAILBOX
CONFIG_TRUSTED_FOUNDATIONS
CONFIG_ARM_SMC_WATCHDOG
CONFIG_CPU_FREQ
CONFIG_CPU_IDLE
CONFIG_ARM_SMCCC_SOC_ID
CONFIG_ARM_SCMI_TRANSPORT_SMC
Patch the kernel clock driver for STM32 to include the clocks formerly
managed by OP-TEE. This requires substantial changes in the kernel source
tree under drivers/clk/stm32, as well as to the device DTS files in
arch/arm/boot/dts. Rather than doing it manually, use the provided patch
file 0004-add-stm32mp1-basic-clock-drivers.patch.
In TF-A, in file plat/st/stm32mp1/bl2_plat_setup.c, add the following lines
at the end of bl2_platform_setup():
/* Allow non-secure access to all RCC clocks */
mmio_write_32(stm32mp_rcc_base() + RCC_SECCFGR, 0);
/* Allow non-secure access to all RTC registers */
#define RTC_SECCFGR 0x20
mmio_write_32(RTC_BASE + RTC_SECCFGR, 0);
Alternatively, apply the patch 0002-unsecure-rcc-rtc.patch.
Now the entire scmi { ... } subtree is no longer needed in
arch/arm/boot/dts/stm32mp131.dtsi. Remove it, and also remove references to
scmi items in this DTS file, and any included from it. Unfortunately, the
optee { ... } node is still required.
Now we’re down to about 75 SMC calls. Steps to cut it down further:
In arch/arm/mach-stm32/KConfig, remove the following line:
select ARM_PSCI if ARCH_MULTI_V7
Open make linux-menuconfig and disable CONFIG_ARM_PSCI (under Kernel
Features -> Support for the ARM Power State Coordination Interface (PSCI)).
This removes about eight SMC calls, including a couple at the very beginning of the boot sequence.
In arch/arm/boot/dts/stm32mp131.dtsi, remove the entire pm_domain { ... }
subtree. Search for references to pd_core_ret and pd_core, and remove
them. This gets rid of another eight or so SMC calls.
(Optional.) Many of the remaining SMC calls are through the OP-TEE driver in
the Linux kernel, drivers/tee/optee/smc_abi.c. In optee_smccc_smc(), add
dump_stack(); at the beginning of the function to trace down all of these
SMC calls.
In the board DTS file, look for the lines:
nvmem-cells = <ðernet_mac1_address>;
nvmem-cell-names = "mac-address";
and replace them with an explicit statement of the MAC address:
mac-address = [00 19 B3 11 00 00];
This way, the kernel does not need to look for the MAC address in NVMEM,
which is under control of OP-TEE. (Alternatively, we can unsecure NVMEM
itself, but that seems like more work.)
Remove also the references to NVMEM in other DTS files, such as the following
lines in arch/arm/boot/dts/stm32mp131.dtsi under cpus/cpu0:
nvmem-cells = <&part_number_otp>;
nvmem-cell-names = "part_number";
And also under adc2:
nvmem-cells = <&vrefint>;
nvmem-cell-names = "vrefint";
Now we can remove the following keys from the kernel configuration:
CONFIG_ARM_SCMI_PROTOCOL
CONFIG_TEE
With that, there is only one more SMC call remaining — the initial SMC call from within OP-TEE to transfer control to Linux. In other words, OP-TEE is now doing nothing at all after Linux gets started. However, before that happens, OP-TEE still does a couple things. Let’s track them down.
Before passing control to Linux, OP-TEE does several things:
Clear the GPIOx_SECCFGR bits to allow non-secure access to GPIO.
Configure the GIC interrupt controller.
Register the SMC handler.
Call the SMC handler, passing DTB address and Linux entry point.
To be able to remove OP-TEE, we have to do these configuration tasks from TF-A, as follows:
In plat/st/stm32mp1/bl2_plat_setup.c, add the GPIO driver header file:
#include <drivers/st/stm32_gpio.h>
Later in the same file, at the end of the function bl2_platform_setup(),
add the code to allow unsecure access to GPIO:
/* Allow non-secure access to all GPIO banks */
for (unsigned int bank = GPIO_BANK_A; bank <= GPIO_BANK_I; bank++) {
uintptr_t base = stm32_get_gpio_bank_base(bank);
unsigned long clock = stm32_get_gpio_bank_clock(bank);
clk_enable(clock);
mmio_write_32(base + GPIO_SECR_OFFSET, 0);
clk_enable(clock);
}
In plat/st/stm32mp1/bl2_plat_setup.c, call the GIC initialization function
at the end of bl2_el3_plat_prepare_exit():
/* Initialize GIC interrupt controller */
stm32mp135_gic_init();
The function needs to be adapted from OP-TEE source code, as follows:
#define GICC_BASE 0xA0022000
#define GICD_BASE 0xA0021000
#define STM32MP135_GIC_MAX_REG 5
#define GICC_PMR (0x004)
void stm32mp135_gic_init(void)
{
for (size_t n = 0; n <= STM32MP135_GIC_MAX_REG; n++) {
/* Disable interrupts */
mmio_write_32(GICD_BASE + GICD_ICENABLER + 4*n, 0xffffffff);
/* Make interrupts non-pending */
mmio_write_32(GICD_BASE + GICD_ICPENDR + 4*n, 0xffffffff);
};
for (size_t n = 0; n <= STM32MP135_GIC_MAX_REG; n++) {
/* Mark interrupts non-secure */
if (n == 0) {
/* per-CPU inerrupts config:
* ID0-ID7(SGI) for Non-secure interrupts
* ID8-ID15(SGI) for Secure interrupts.
* All PPI config as Non-secure interrupts.
*/
mmio_write_32(GICD_BASE + GICD_IGROUPR + 4*n, 0xffff00ff);
} else {
mmio_write_32(GICD_BASE + GICD_IGROUPR + 4*n, 0xffffffff);
}
}
/* Set the priority mask to permit Non-secure interrupts, and to
* allow the Non-secure world to adjust the priority mask itself
*/
mmio_write_32(GICC_BASE + GICC_PMR, GIC_HIGHEST_NS_PRIORITY);
}
Note that this function cannot be called from bl2_platform_setup(), at
least not without further modifications to the code. The STM32MP135 manual
says that “Memory regions marked as normal memory cannot access any of the
GIC registers, instead access caches or external memory as required.” The
function bl2_platform_setup() is run with MMU enabled, so attempting to
access the registers directly probably causes a page fault; all I can see is
that the device freezes.
In bl2/aarch32/bl2_run_next_image.S, define the following constants:
#define CPSR_MODE_SVC U(0x13)
#define CPSR_I BIT(7)
#define CPSR_F BIT(6)
#define SCR_NS (1U << 0)
#define ACTLR_SMP (1U << 6)
#define SCTLR_M (1U << 0)
#define SCTLR_C (1U << 2)
#define SCTLR_I (1U << 12)
#define SCTLR_TE (1U << 30)
#define SCTLR_SPAN (1U << 23)
#define SCTLR_A (1U << 1)
Define the following macros:
.macro write_actlr reg
mcr p15, 0, \reg, c1, c0, 1
.endm
.macro read_actlr reg
mrc p15, 0, \reg, c1, c0, 1
.endm
.macro read_sctlr reg
mrc p15, 0, \reg, c1, c0, 0
.endm
.macro write_sctlr reg
mcr p15, 0, \reg, c1, c0, 0
.endm
.macro write_mvbar reg
mcr p15, 0, \reg, c12, c0, 1
.endm
.macro read_scr reg
mrc p15, 0, \reg, c1, c1, 0
.endm
.macro write_scr reg
mcr p15, 0, \reg, c1, c1, 0
.endm
Define the SMC handler:
func sm_smc_entry
/* Update SCR */
read_scr r0
orr r0, r0, #SCR_NS
write_scr r0
mov r0, #0
/* Return from the secure monitor call */
push {r4}
push {r3}
rfefd sp
endfunc sm_smc_entry
Define the SM vector table:
func sm_vect_table
.balign 32
b . /* Reset */
b . /* Undefined instruction */
b sm_smc_entry /* Secure monitor call */
b . /* Prefetch abort */
b . /* Data abort */
b . /* Reserved */
b . /* IRQ */
b . /* FIQ */
endfunc sm_vect_table
In the same file, replace bl2_run_next_image with the following function:
func bl2_run_next_image
mov r8,r0
/*
* MMU needs to be disabled because both BL2 and BL32 execute
* in PL1, and therefore share the same address space.
* BL32 will initialize the address space according to its
* own requirement.
*/
bl disable_mmu_icache_secure
stcopr r0, TLBIALL
dsb sy
isb
mov r0, r8
bl bl2_el3_plat_prepare_exit
/* Enable coherent requests to the processor */
read_actlr r0
orr r0, r0, #ACTLR_SMP
write_actlr r0
/* Setup core configuration in CP15 SCTLR */
read_sctlr r0
bic r0, r0, #SCTLR_M /* disable MPU */
bic r0, r0, #SCTLR_C /* disable data and unified caches */
bic r0, r0, #SCTLR_I /* disable instruction caches */
bic r0, r0, #SCTLR_TE /* exceptions taken in ARM state */
orr r0, r0, #SCTLR_SPAN
bic r0, r0, #SCTLR_A /* disable alignment fault checking */
write_sctlr r0
isb
/* Set monitor vector (MVBAR) */
ldr r0, =sm_vect_table
write_mvbar r0
/* Will switch to SVC mode with IRQ and FIQ disabled */
mov r4, #(CPSR_MODE_SVC | CPSR_I | CPSR_F)
/* Linux entry address */
ldr r3, [r8, #ENTRY_POINT_INFO_LR_SVC_OFFSET]
/* Linux arguments */
add r8, r8, #ENTRY_POINT_INFO_ARGS_OFFSET
ldm r8, {r0, r1, r2}
/* Call the Secure Monitor handler */
mov r1, #0
mov r0, #0
smc #0
endfunc bl2_run_next_image
In plat/st/stm32mp1/bl2_plat_setup.c, add the header files for TrustZone
memory protection:
#include <drivers/arm/tzc400.h>
#include <dt-bindings/soc/stm32mp13-tzc400.h>
In the same file, remove function prepare_encryption() entirely. Remove the
body of the function bl2_plat_handle_post_image_load() and replace it with
a simple return 0;.
In bl2_el3_plat_prepare_exit(), remove the statement
stm32mp1_security_setup(); and replace it with the following:
/* Configure TrustZone memory protection */
tzc400_init(STM32MP1_TZC_BASE);
tzc400_disable_filters();
tzc400_configure_region0(TZC_REGION_S_NONE, TZC_REGION_NSEC_ALL_ACCESS_RDWR);
tzc400_set_action(TZC_ACTION_INT);
tzc400_enable_filters();
Now that OP-TEE no longer runs, there is no need to load it in the FIP package
or the memory. Remove it as follows:
In TF-A (bl2/aarch32/bl2_run_next_image.S), in bl2_run_next_image,
replace ENTRY_POINT_INFO_LR_SVC_OFFSET with ENTRY_POINT_INFO_PC_OFFSET.
In plat/st/stm32mp1/plat_bl2_mem_params_desc.c, remove the entries
corresponding to BL32_IMAGE_ID, BL32_EXTRA1_IMAGE_ID,
BL32_EXTRA2_IMAGE_ID, and TOS_FW_CONFIG_ID.
In entries for HW_CONFIG_ID and BL33_IMAGE_ID, replace
IMAGE_ATTRIB_SKIP_LOADING with 0.
For all three entries, fill out the image_base and image_max_size fields,
as follows. For FW_CONFIG_ID, add:
.image_info.image_base = STM32MP_FW_CONFIG_BASE, .image_info.image_max_size = STM32MP_FW_CONFIG_MAX_SIZE,
For HW_CONFIG_ID, add:
.image_info.image_base = STM32MP_HW_CONFIG_BASE,
.image_info.image_max_size = STM32MP_HW_CONFIG_MAX_SIZE,
For BL33_IMAGE_ID, add:
.image_info.image_base = STM32MP_BL33_BASE,
.image_info.image_max_size = STM32MP_BL33_MAX_SIZE,
For BL33_IMAGE_ID, add the EP_FIRST_EXE flag to the flags already given
in SET_STATIC_PARAM_HEAD(). Add the following line:
.ep_info.pc = STM32MP_BL33_BASE,
In Buildroot configuration (make menuconfig), under Bootloaders, disable
optee_os (BR2_TARGET_OPTEE_OS).
Under “Additional ATF build variables”
(BR2_TARGET_ARM_TRUSTED_FIRMWARE_ADDITIONAL_VARIABLES), remove
AARCH32_SP=optee.
In the TF-A Makefile, remove the line that says NEED_BL32 := yes.
All the above changes to TF-A can also be found in 0003-remove-optee.patch.
STM32MP135 presents an SDK that is, to my mind, overly complicated. To port the setup from the evaluation board to a new board requires the understanding of three bootloaders (ROM, TF-A, U-Boot), two operating systems (Linux, OP-TEE), and a stack of other software. Most of this arose out of a desire to simplify the process; for example, U-Boot aims to be the one universal bootloader in embedded systems, so as to not have to learn a new one for each platform. But the ironic end result is that after piling on so many “simplifications”, the net result is more complicated than having none of them.
The claim that OP-TEE is mandatory probably arises out of a desire to avoid having to maintain two separate development branches, a secure and a non-secure one. This must be even more so considering the need to support the GUI-based configuration utilities (STM32Cube), or the Yocto-based distributions.
However, as a developer I would prefer to be offered a minimal working configuration where OP-TEE would be an “opt-in” configuration, rather than tightly bundling it in with the kernel. Many (most?) applications do not call for secure-world services; these get included only due to the large cost of removing it from the provided SDKs.
TBD
ST wiki: How to disable OP-TEE secure services ↩︎
